What is the knowledge of aluminum honeycomb panel

　  aluminum honeycomb panelThe composite honeycomb structure is formed by hot pressing of preformed box-shaped face plate and back plate and aluminum alloy honeycomb core material. The high-quality 3003H24 alloy aluminum plate 5052AH14 high-manganese alloy aluminum plate is selected as the base material. The panel thickness is 0.5~1.5mm fluorocarbon roll-coated plate, and the bottom plate thickness is 0.5~1.0mm. The aluminum honeycomb core material is hexagonal 3003 core material, and the aluminum foil thickness is 0.04~0.06mm, and the side length is 5~6mm.

honeycomb composite technology

(1) The scientific and technological achievements derived from modern aviation are lighter in weight, but the strength of the plate is higher.

(2) The use of high-temperature composite and panel hot pressing technology to ensure the integrity, strength and flatness of the board.

Features of honeycomb aluminum sheet Products:

Sound insulation, heat insulation, fire prevention, wind pressure resistance, earthquake resistance, good weather resistance, and convenient processing and installation.

The advantages of aluminum honeycomb panel partition performance

(1) Fire prevention: aluminum plate is non-combustible material.

(2)arc honeycomb panelCorrosion resistance: aluminum honeycomb panel is treated with epoxy fluorocarbon on the surface, which has strong corrosion resistance. Salt spray for 48 hours without pinhole, crack, no bubble.

(3) Environmental protection: Honeycomb panels are pure aluminum Products, do not volatilize any harmful gases, non-radioactive and can be completely recycled, 100% environmentally friendly Products.

(4) the aluminum honeycomb panel is easy to dismantle and assemble, and will not dismantle the bad plate. Due to its light weight and convenient transportation, it can be transported to different places for repeated use. This is the other partition plate can not be compared.

Common Installation Method of Aluminum Honeycomb Panel Curtain Wall

1. Lug type

This installation method is to separate the lifting lug and the honeycomb panel. After the lifting lug is processed separately, it is connected to the glue seam position of the honeycomb panel. The suitable width of the glue seam is ≥ 12mm. This installation method makes the processing simple and the installation convenient.

2. Flip type

This installation method is to process the aluminum honeycomb panel with flanging for installation,Stone Honeycomb PanelThe installation only needs to comfort the connection with the keel and glue seam, and the suitable glue seam width is ≥ 10mm. This method is convenient to install, but the processing is slightly complicated and is not suitable for modeling curtain wall panels.

3. Buckle type

This node is aluminum buckle strip type, buckle strip is a specific profile, easy to install, but this method requires high machining accuracy of the plate, it is not recommended to use the length of more than 3000mm plate. According to the width of the buckle strip, the plate is sewn with 20mm and 40mm, etc.
