What are the properties of aluminum honeycomb panels

　　aluminum honeycomb panelThe performance of decorative panels is generally made of 3003, 5005 and other brands, and 1100 plates with low alloy composition are rarely used. Decorative surface by spraying or roller coating form, coating for polyester or fluorocarbon paint, exterior wall board is best choice of spraying board, and requires more than three coating, paint layer thickness ≥ 40μm, so as to ensure the durability of the coating.

The aluminum plate needs to undergo strict surface anodization treatment before painting to ensure sufficient coating adhesion and bonding strength with the honeycomb core. The panel coating should meet the requirements of the national specification YS/T429.2-2000.

The performance of aluminum honeycomb panels should be made of the same material as the panel. The surface should be anodized, and the side exposed to the air should be coated with a protective coating. The coating materials can be polyester, epoxy, acrylic and other materials to prevent long-term exposure to the air and cause corrosion of the aluminum plate.

Properties of aluminum honeycomb panel

(1) Fire prevention: aluminum plate is non-combustible material.

(2) Corrosion resistance: The surface of the aluminum honeycomb panel is treated with epoxy fluorocarbon, which has strong corrosion resistance. Salt spray for 48 hours without pinhole, crack, no bubble.

(3) Environmental protection:Stone Honeycomb PanelIt is a pure aluminum product, which does not volatilize any harmful gas to the human body, has no radioactivity and can be completely recycled, and is a hundred percent environmentally friendly product.

(4) the aluminum honeycomb panel is easy to dismantle and assemble, and will not dismantle the bad plate. Due to its light weight and convenient transportation, it can be transported to different places for repeated use. This is the other partition plate can not be compared.

Aluminum honeycomb panel installation method

1. Lug type

This installation method is to separate the lifting lug and the honeycomb panel. After the lifting lug is processed separately, it is connected to the glue seam position of the honeycomb panel. The suitable width of the glue seam is ≥ 12mm. This installation method makes the processing simple and the installation convenient.

2. Flip type

This installation method is to process the flanging for installation when processing the aluminum honeycomb panel, and the installation only needs to comfort the connection with the keel and glue seam,arc honeycomb panelThe appropriate glue seam width is ≥ 10mm, this method is easy to install, but the processing is slightly complicated, and it is not suitable for modeling curtain wall panels.

3. Buckle type

This node is aluminum buckle strip type, buckle strip is a specific profile, easy to install, but this method requires high machining accuracy of the plate, it is not recommended to use the length of more than 3000mm plate. According to the width of the buckle strip, the plate is sewn with 20mm and 40mm, etc.
