Installation effect of aluminum honeycomb floor

Article Source: Guangzhou Kaimai Metal Building Materials Co., Ltd. 人气:-Published: 2017-01-29 00:00:00

  Aluminum Honeycomb FloorThe whole processing process is completed in a modern factory. Hot pressing molding technology is adopted. Due to the high thermal conductivity value between the aluminum skin and the honeycomb, the thermal expansion and cold contraction of the inner and outer aluminum skin are synchronized. There are small holes in the honeycomb aluminum skin, so that the gas in the plate can flow freely.

The sliding mounting buckle system will not cause structural deformation during thermal expansion and contraction, so it can ensure extremely high flatness. Adopt adhesive: two-component polyurethane high-temperature curing adhesive, with full-automatic honeycomb board composite production equipment through pressurized high-temperature composite, to overcome the brittleness of the previous honeycomb board adhesive layer.

  Stone Honeycomb PanelScope of application: all kinds of large public building channels, airports, exhibition halls, shopping centers, stations, Tunnel corridors, etc.

The core material of aluminum honeycomb floor adopts hexagonal 3003 aluminum honeycomb core with aluminum foil thickness of 0.04~0.06mm and side length of 5~6mm. The forming of front and back skins is completed by roll forming technology, and the front and back skins are folded by full-automatic machinery and equipment. The front and back skins are tightly occluded at the installation edge. The whole processing process is completed in a modern factory, using hot pressing technology, because of the high thermal conductivity between the aluminum skin and the honeycomb, the thermal expansion and contraction of the inner and outer aluminum skin are synchronized.

Aluminum Honeycomb Floor

According to the indoor acoustic design, different perforation rate design can be carried out, and the sound absorption coefficient of the combined structure can be controlled within a certain range, which not only achieves the design effect, but also can reasonably control the cost.

Aluminum honeycomb floor is set into a honeycomb panel, of course, also has its characteristics, the following is the function of aluminum honeycomb floor:

  arc honeycomb panelFeatures: sound insulation, heat insulation, fire prevention, shockproof function outstanding.

(1) fire: aluminum plate for non-combustible materials.

(2) corrosion resistance: aluminum honeycomb panel is the appearance of the epoxy fluorocarbon treatment, with strong corrosion resistance. Salt spray for 48 hours without pinhole, crack, no bubble.

Aluminum Honeycomb Floor

(3) Environmental protection:aluminum honeycomb panelIt is a pure aluminum product, which does not evaporate any harmful gas to the human body, has no radioactivity and can be completely recovered for use, and is 100% environmentally friendly.
