What are the uses of aluminum honeycomb panels

　　aluminum honeycomb panelOriginally used in the aviation manufacturing industry, its use is very wide, in the elevator decoration engineering, rail transit vehicle decoration, ship interiors, building curtain walls, electronic whiteboards, stadiums, shelters and many other industries have applications.

The panel mainly uses high-quality 3003H24 alloy aluminum plate or 5052AH14 high-manganese alloy aluminum plate as the substrate, and the panel thickness is 0.8-1 . 5mm fluorocarbon roll-coated board or light-resistant baking varnish. The light-resistant baking varnish is stronger than PVDF in terms of scratch resistance, acid rain corrosion discoloration and self-cleaning. The thickness of the bottom plate is 0.6-1 . Omm, with a total thickness of 25mmo. The core material adopts hexagonal 3003 aluminum honeycomb core, the thickness of aluminum foil is 0.04-0.06mm, and the side length is 5-6mm. The forming of the front and back skins is completed by roll forming technology. The full-automatic machine equipment is folded, and the front and back skins are tightly occluded at the installation edge.

　　Stone Honeycomb PanelThe use of composite honeycomb structure, by pre-formed box-shaped panel and back plate and aluminum alloy honeycomb core hot-pressing composite molding. The high-quality 3003H24 alloy aluminum plate 5052AH14 high-manganese alloy aluminum plate is selected as the base material. The panel thickness is 0.5~1.5mm fluorocarbon roll-coated plate, and the bottom plate thickness is 0.5~1.0mm. The aluminum honeycomb core material is hexagonal 3003 core material, and the aluminum foil thickness is 0.04~0.06mm, and the side length is 5~6mm.

Aluminum honeycomb panel features

(1) Light weight, high strength, high rigidity, stable structure and good wind pressure resistance

(2) Sound insulation, heat insulation, fire prevention and shockproof functions can be outstanding

(3) the surface has amazing flatness, and color diversity

(4) strong decorative, easy to install, fast

　　arc honeycomb panelUses: building curtain wall decoration, ceiling, buses, trains, subway and rail transit vehicles, commercial transport vehicles and container car bodies, shipboard buildings, billboards, interior decoration projects.

Aluminum honeycomb panel has the following aspects of high quality performance:

1. Light weight, high strength, high rigidity and stable structure;

2. Green environmental protection and energy saving;

3. Sound insulation, heat insulation, fire prevention and shockproof;

4. Strong decoration, convenient and fast installation, flat surface and diversified colors.
