How about the material selected for aluminum honeycomb panel

　　How about the material selected for aluminum honeycomb panel?The aluminum honeycomb panel adopts a composite honeycomb structure, which is formed by hot pressing of preformed box-shaped face plate and back plate and aluminum alloy honeycomb core material. High-quality 3003H24 alloy aluminum plate 5052AH14 high-manganese alloy aluminum plate is selected as the base material. The thickness of the panel is 0.5~1.5mm fluorocarbon roll-coated plate, and the thickness of the bottom plate is 0.5~1.0mm. The aluminum honeycomb core material selected for the aluminum honeycomb plate is hexagonal 3003 core material, the thickness of the aluminum foil is 0.04~0.06mm, and the side length is 5~6mm.

　　aluminum honeycomb panelUses: building curtain wall decoration, ceiling, buses, trains, subway and rail transit vehicles, commercial transport vehicles and container car bodies, shipboard buildings, billboards, interior decoration projects.

Aluminum honeycomb panels were originally used in the aviation manufacturing industry. They are widely used in elevator decoration engineering, rail transit vehicle decoration, ship interiors, building curtain walls, electronic whiteboards, stadiums, bus shelters and many other industries.

　　arc honeycomb panelThe panel mainly uses high-quality 3003H24 alloy aluminum plate or 5052AH14 high-manganese alloy aluminum plate as the base material, and the thickness of the panel is 0.8-1 . 5mm fluorocarbon roll-coated board or light-resistant baking varnish. The light-resistant baking varnish selected for aluminum honeycomb board is stronger than PVDF in terms of scratch resistance, acid rain corrosion discoloration and self-cleaning. The thickness of the bottom plate is 0.6-1 . Omm, with a total thickness of 25mmo. The core material adopts hexagonal 3003 aluminum honeycomb core, the thickness of aluminum foil is 0.04-0.06mm, and the side length is 5-6mm. The forming of the front and back skins is completed by roll forming technology. The full-automatic machine equipment is folded, and the front and back skins are tightly occluded at the installation edge. Using advanced molding technology, the entire processing process is completed in a modern factory.

　　Stone Honeycomb PanelThe inner layer is a special hexagonal aluminum honeycomb, composed of aluminum alloy with a hardness of H19, which acts as a core plate adhered in the sandwich structure and bears pressure in the tangential direction. These mutually restrained dense honeycombs are like many small I-beams, which can be dispersed to bear the pressure from the direction of the panel, so that the plate is evenly stressed and ensures that the panel can still maintain a high flatness in a large area.
