Introduction of Common Installation Methods for Aluminum Honeycomb Panel Curtain Wall

Article Source: Guangzhou Kaimai Metal Building Materials Co., Ltd. 人气:-Published: 2016-11-24 17:42:00

  Common Installation Method of Aluminum Honeycomb Panel Curtain WallI: Lug type

This installation method is to separate the lifting lug and the honeycomb panel. After the lifting lug is processed separately, it is connected to the glue seam position of the honeycomb panel. The suitable width of the glue seam is ≥ 12mm. This installation method makes the processing simple and the installation convenient.

  aluminum honeycomb panelCurtain wall commonly used installation method two: flanging type

This installation method is to process the flanging for installation when processing the aluminum honeycomb panel. The installation only needs to comfort the connection with the keel and glue seam. The suitable glue seam width is ≥ 10mm. This method is convenient to install, but the processing is slightly complicated and is not suitable for modeling curtain wall panels.

Aluminum honeycomb panel curtain wall commonly used installation method three: buckle type

This node is aluminum buckle strip type, buckle strip is a specific profile, easy to install, but this method requires high machining accuracy of the plate, it is not recommended to use the length of more than 3000mm plate. According to the width of the buckle strip, the plate is sewn with 20mm and 40mm, etc.

aluminum honeycomb panel

Selection requirements of raw materials for manufacturing aluminum honeycomb panels

Aluminum decorative panel

Aluminum honeycomb panel decorative panels are generally made of 3003, 5005 and other brands, and 1100 plates with low alloy composition are rarely used. The decorative surface shall be in the form of spraying or roller coating,Mirror honeycomb panelThe coating is polyester or fluorocarbon paint, the best choice for exterior wall panels, and requires more than three coatings, the thickness of the paint layer ≥ 40μm, so as to ensure the durability of the coating.

The aluminum plate needs to undergo strict surface anodization treatment before painting to ensure sufficient coating adhesion and bonding strength with the honeycomb core. The panel coating should meet the requirements of the national specification YS/T429.2-2000.

Aluminum back plate

The aluminum honeycomb panel backplane shall be made of the same material as the panel,stainless steel honeycomb plateThe surface is anodized, and the side exposed to the air should be coated with a protective coating. The coating material can be polyester, epoxy, acrylic and other materials to prevent long-term exposure to the air from causing corrosion of the aluminum plate.
