Aluminum veneer is different from aluminum honeycomb panel

From the process point of view, the difference between the two: curtain wall aluminum veneer is a single-layer product, the processing is relatively simple, the modeling ability is strong, but the accuracy is poor;aluminum honeycomb panelFor composite Products, the processing speed and ability are weak, but the accuracy is guaranteed.

What are the differences in installation: the box-type honeycomb aluminum plate adopts a buckle cover system, and there are two systems to choose from: exposed glue seam and hidden glue seam. The system fully considers the influence of thermal expansion and cold contraction on the plate surface itself. The four directions of the plate surface can expand and contract freely, and the aluminum honeycomb plate effectively avoids the influence of temperature stress on the flatness of the plate surface. Ordinary single-layer aluminum plate only has glue seam exposure system, and the installation is fixed on the keel with installation code, there is no suitable space to release temperature stress, resulting in warping of the plate surface.

The characteristics of aluminum honeycomb panel: aluminum honeycomb panel is a composite plate, which has the advantages of light weight, high strength, good flatness, large surface, easy installation, easy maintenance, good environmental protection, reusable, excellent thermal expansion and contraction resistance, etc.

The characteristics of curtain wall aluminum veneer: curtain wall aluminum veneer is ordinary non-composite plate, compared with aluminum honeycomb panel, does not have the above advantages, but in comparison, the cost of 3MM thick curtain wall aluminum veneer is generally lower than 25MM aluminum honeycomb panel 15 to 20%. Because of its own weight and forming reasons, 4MM thick curtain wall aluminum veneer is rarely used in construction, and the cost of curtain wall aluminum veneer with this thickness is only about 5% different from that of aluminum honeycomb panel Products.
