Core Technical Requirements for Research and Development of Honeycomb Aluminum Plate

In order to achieve the goal of beautiful, practical and recyclable value of honeycomb aluminum plate, several aspects are very critical in the process of research and development, whether it is inaluminum honeycomb panelAt the beginning of the material blanking stage or in the installation process of the product, must be strictly observed, strict each process, in order to achieve the desired effect:

(1) The requirements for the installation of the base are very high: the steel frame after forming, the inner and outer arc formwork production accuracy requirements are very high; otherwise the curved aluminum plate that is processed and formed cannot be installed;

(2) The processing requirements for facing honeycomb aluminum plates are very high: the inner arc and outer arc of the single-curved aluminum plate should be reasonable and accurate, the curved aluminum plate of the elevation should be processed by mold, and the other folded aluminum plates should be processed by the same principle, and then the aluminum plates should be welded one by one into unit aluminum plates according to the primary and secondary order. Finally, the welded parts should be polished and polished, the surface should be treated with powder or fluorocarbon, and the bracket should be packaged to avoid deformation. Because of aluminum welding, the thickness of the aluminum plate base layer is required to be 3mm and above, so as to ensure that the aluminum plate does not blister or deform during welding;

(3) the product installation requirements are very high: two adjacent aluminum plate fixed angle code and lock type angle code processing position should be very accurate;

(4) The arc-shaped aluminum plate joints shall be closely spliced to control the angle and length of the inner arc and the outer arc to ensure that the vertical and horizontal gaps are completely closely spliced without opening. That is, the process of wide seam sealant can be omitted, saving costs, while improving the beauty and natural perception.

A successful single surface finish honeycomb aluminum wall, with each of the above key technologies is inseparable, indispensable. The above technical requirements can be strictly in place, and we are very smooth in the installation, which improves the installation process, shortens the construction period and reduces the production cost.
